Mobile 1400HD Grain Feeder

From: $3,795.00
+ GST

The M1400HD Grain Feeder from Advantage Feeders provides reliable feed control and flexibility, making it ideal for mixed livestock operations including cattle, sheep, goats, and deer.

With an 28.4 bu capacity, this feeder is well-suited for paddock or feedlot use, accommodating multiple stock classes while minimizing refill frequency and maximizing feed efficiency - all with the added convenience of on‑farm towing.

The M1400HD has been designed specifically for navigating wet conditions and comes equipped with flotation tyres.

The trailer features an adjustable height hitch, and two retractable stabilizer stands to secure the feeder safely when in use. It also has a real pull to tow multiple units together!

Lamb creep feeding panel included.

*Please note: Mobile units are designed for on‑farm towing only and are not approved for public road use. Do not exceed 25km per hour.

$3,795.00
+ GST
Product Assembly Options:
  • Feed capacity: 28.4 bu
  • Cattle or calves (paddock): 40 – 50 head
  • Cattle (feedlot): 30 – 35 head
  • Ewes or lambs (paddock): 200 – 250 head
  • Ewes or lambs (feedlot): 120 – 150 head
  • Ewes and lambs (creep feeding): 200 – 250 combined
  • Goats (paddock): 200 – 250 head
  • Deer (paddock): 120 – 150 head
  • Pigs: 120 – 150 head
  • Heavy-duty construction: Built to withstand rugged farm use
  • Adjustable height: Adjustable height settings for sheep, goats, and extended cattle heights

3-way Restriction System

At the core of the M1400HD is Advantage Feeders’ precise 3‑way restriction system, which lets you control feed intake and encourage healthy feeding behaviour while preventing waste.

The saliva restriction system requires stock to lick feed from a groove through the Adjuster Guard, naturally supporting a little and often feeding approach. This controls ration size, reduces overeating and bullying, reduces feed wastage, and ensures all animals have fair, controlled access.

Benefits of controlled feeding

  • Improve feed conversion efficiency
  • Support consistent weight gain
  • Reduce grain wastage and input costs
  • Maintain healthier rumen function

Dimensions & Weight

  • Overall Weight: 640 lb
  • Length: 11.4’
  • Width: 4.3’
  • Dimensions at Sheep Height: 11.4’ × 4.3’ × 3.8’
  • Dimensions at Cattle Height: 11.4’ × 4.3’ × 4.4’
  • Axle Rating: 1 ton
  • Tyre Rating: 1 ton
  • Tyre Size: 22-11-8 (6 Ply)

Feed Capacity & Weight

  • Feed Volume: 28.4 bu
  • Feed Weight – Wheat/Lupins: 1698 lb
  • Feed Weight – Barley/Pellets: 1433 lb
  • Feed Weight – Oats: 1146 lb

This feeder is built with reinforced stainless-steel troughs, upper adjusters, and solid lower adjusters for long-term durability, complemented by two standard adjuster guards with dedicated storage when not in use. It features two 1.5” SHS stands and offers both sheep and cattle height options, constructed from Z275 sheet metal with stainless steel and galvanised dipped components. The 45-degree angled trough, deep 4.3’ trough depth, and rain protection reinforcing improve feed access and durability, while sidewall bracing, three adjuster braces, and dual tab adjuster braces enhance structural strength.

Feed control is supported by four locking bolts on the lower adjusters, an adjuster guard locking system, and a dual-positioned adjuster guard for dusty feeds. Additional features include two 3” round sight glasses, volume stickers, a painted notch system on the adjusters, and a 7.8’ trough length. The feeder is designed for convenience with adjustable height in around 30 minutes, supplied cleaning tools and tube spanner with secure storage, and two new tyres for mobility.

Practical additions such as sidewall gutters for drainage, reinforced roof edges, optional mineral attachment and lamb creep feeding panel, along with a 2 year warranty, standard operating procedure, user guide, and available trial reports, make it a well-rounded and user-friendly solution.

Accessories
Mineral attachments, rubber mats, creep panels and gates to extend your feeder as your operation’s needs change.

The Advantage Feeders Rubber Mats provides durable ground protection around your feeders, reducing mud, soil erosion, and wear in high-traffic livestock areas.

+ GST

The Advantage Feeders Mineral Attachment is a purpose‑built livestock mineral feeder designed to provide loose lick and mineral supplements to stock without waste. It’s engineered to be versatile and easy to deploy across farm environments, with sturdy brackets included to hang the unit on gates, fences, posts, or directly onto Advantage Feeders equipment.

+ GST

A pair of heavy‑duty hungry boards that bolt onto Advantage Feeders to widen the fill opening by ~16 in, making loader filling faster and reducing waste.

+ GST
