Description
| Weight: | 750lbs |
|
Dimensions :
|
8’0″ x 5’5″ x 4’9″ (LxWxH)
|
|
Feed Volume:
|
24bu |
|
Feed weight – wheat/corn:
|
1.5 tons |
|
Feed weight – barley/pellets:
|
1.3 tons |
|
Feed weight – oats:
|
1.1 tons |
| Cattle: | 50 |
| Sheep: |
150
|
- NEW numbered Adjuster Guard Handle design
- NEW Cleaning Tool and Tube Spanner locations
- NEW Flow Assist
- NEW Adjuster Lock
- Upgraded Roof Pivot
- Reinforced stainless steel troughs
- Reinforced stainless steel upper adjusters
- Reinforced stainless steel lower adjusters
- 2x adjuster guards standard
- Adjuster guard housing when not in use
- 4x 2.4″ SHS skids
- High stability with hopper wholly over skids
- 2x 2.5″ SHS braces between the skids
- Hot gal dipped skids
- Anti-slip platform between skids
- Laser cut corners in skids to prevent rust
- Z275 sheetmetal
- Rain protection reinforcing
- Side wall bracing
- Channel roof pivot bracket
- 2x 8″×4″ RHS tine guides
- Adjustable width tine guides
- 6x adjuster braces
- Dual tab adjuster braces
- 4x locking bolts on the lower adjusters
- Adjuster guard locking system
- Dual positioned adjuster guard for dusty feeds
- 4x 3″ round sight glasses
- Vertical side wall bracing for easy feed flow
- 2x volume stickers
- Adjust feeder height in just 15 minutes
- Cleaning tool supplied
- Tube spanner supplied
- Secure housing for tools
- 94″mm trough length
- Painted notch system on the adjusters
- Deep 4.5″ trough depth
- Gutters on side walls drain out of feeder
- Weather protection over the troughs
- Reinforced roof edges
- Mineral attachment option
- Calf creep feeding gate option
- Lamb creep feeding panel option
- Rubber mat option
- Standard operating procedure supplied
- User guide supplied
- Trial reports available
