Description
| Weight: | 420lbs |
|
Dimensions :
|
4’0″ x 5’5″ x 4’9″ (LxWxH)
|
|
Feed Volume:
|
25 bu |
|
Feed weight – wheat/corn:
|
0.7 tons |
|
Feed weight – barley/pellets:
|
0.6 tons
|
|
Feed weight – oats:
|
0.5 tons
|
| Cattle: | 25 |
| Sheep: | 75 |
| Goats: |
75
|
- NEW numbered Adjuster Guard Handle design
- NEW Cleaning Tool and Tube Spanner locations
- NEW Flow Assist
- NEW Adjuster Lock
- Upgraded Roof Pivot
- Reinforced stainless steel troughs
- Reinforced stainless steel upper adjusters
- Reinforced stainless steel lower adjusters
- 2x adjuster guards standard
- Adjuster guard housing when not in use
- 2x 2.5″ SHS skids
- High stability with hopper wholly over skids
- Hot gal dipped skids
- Laser cut corners in skids to prevent rust
- Channel reinforced trough
- Z275 sheetmetal
- 45 degrees angled trough
- 4″ feed flow area
- Rain protection reinforcing
- Side wall bracing
- Channel roof pivot bracket
- 2x 8″x4″ RHS tine guides
- 2x adjuster braces
- Dual tab adjuster braces
- 2x locking bolts on the lower adjusters
- Adjuster guard locking system
- Dual positioned adjuster guard for dusty feeds
- 4x 3″ round sight glasses
- Vertical side wall bracing for easy feed flow
- 2x volume stickers
- Adjust feeder height in just 15 minutes
- Cleaning tool supplied
- Tube spanner supplied
- Secure housing for tools
- 63″ trough length
- Painted notch system on the adjusters
- Drop lock pin roof locking system
- Deep 4.5″ trough depth
- Gutters on side walls drain out of feeder
- Weather protection over the troughs
- Reinforced roof edges
- Mineral attachment option
- Calf creep feeding gate option
- Lamb creep feeding panel option
- Rubber mat option
- Standard operating procedure supplied
- User guide supplied
- Trial reports available
